Size (Closed W/O AC): 2265mmW x 5580mmL x 2800mmH
Style: 12’ hybrid offroad caravan
Towball Weight: 170kg
Tare Weight: Approx. 1830kg
ATM: 3000kg
Berth: 2
Chassis: 150mm x 50mm x 3mm
Drawbar: 150mm x 50mm x 4mm
Body Construction: Aluminium composite panel fully welded frame + chassis
Stone Guard: Included with stone tamer mudflaps
Suspension: Independent trailing arm with 4x shock absorbers and coil springs
Wheels & Tyres: 265/75 R16 Goodride radial mud terrain
Coupling: DO35
Brakes: 4WD 12” electric with hand brake
Gas Cylinders: 2 x 9kg gas cylinder holders
Jerry Can Holder: 2 x 20L jerry can holders
Kitchen Construct: Thetford External 304 grade stainless steel with 3 burner gas cooktop, stainless steel sink with washboard, hot and cold water to kitchen
Water Tank: 2 X 80L fresh water
Water Delivery: 12V electric pump
Hot Water System: Truma “Boiler” 14L (gas)
Shower (Ensuite): Hot/cold external includes van side mounted shower tent
Awning: Electric
Battery: 2 x 100amp 12V deep cycle batteries
Inverter: Projecta 12v 1000w modified Sine inverter
Outlets: Multiple 12V, 240V x 2
Jockey Wheel: 10” swing up and lockable
Stabiliser Legs: 4 x heavy duty lockable and adjustable drop down
Light Connection Plug: 12pin flat as standard. 7 pin round or 7 pin flat connection available
Mattress: 200mm custom Queen inner spring
Sound: Kenwood head unit with internal & external speakers
Solar: 2 x 150W solar included Diesel heater *All weights do not include gas bottles, jerry cans, annex walls & roof. XT-12 HR model on the yard now.

Featuring a compact design, full external kitchen and fridge slide & internal ensuite the XT12HR has it all in the most compact offroad caravan package to date!

Ring Bevin Muir

Gateway RV Centre

KOPU THAMES

0274621142
